Product images are for illustration purposes only. Please review specifications and documentation for exact product details.
Series
CWM150-22-30E10 WEG Electric Contactors, CWM Series
MFG #:
CWM150-22-30E10
Contactor, 3-P N/O, 120VAC, 150A 110-130VAC/DC Coil, 2NO/2NC Aux Cntc 60Hp@230V/125HP@460V, Elect. Coil
Specifications
| Manufacturer Part Number | CWM150-22-30E10 |
|---|---|
| Manufacturer | WEG Electric |
| Product Series | CWM |
| Family Series | WEG Electric Contactors, CWM Series |
| Type | AC Non-Reversing IEC |
| Nominal Coil Voltage | 120 VAC, 125 VDC |
| Coil Voltage | 110-130 VAC, 110-130 VDC |
| Coil Type | Electronic |
| Poles | 3NO |
| Frame Size | CWM150 |
| Auxiliary Contact | 2NO, 2NC |
| Termination | Screw |
| Overload Relays | RW117-2D3, RW317-1D3 |
| General Purpose (AC1) | 225 A |
| UL Motor Switching (AC3) | 150 A |
| H x W x D | 5.71 " x 4.78 " x 6.40 " |
| Net Weight | 6.754 lbs |
| Gross Weight | 6.754 lbs |
Description
Contactors, CWM Series
Item #
CWM150-22-30E10
Contactor, 3-P N/O, 120VAC, 150A
CWM Series Information
- 24~600 VAC/VDC Coils
- Up to 300 HP @ 240V
- Up to 600 HP @ 460V
- UL, IEC, CE Approved
- Up to 800 Amps
- IP20 Finger Protection
- CSA Certified
Documents & Resources Links
Videos
Accessories
Compare compatible accessories for this product.
| Image | Part | Description | Series | Type | Price | Action |
|---|---|---|---|---|---|---|
|
|
BCE-150E10 | Coil 110-130V For | Coil |
Price unavailable
|
||
|
BCXML11 | Auxiliary Contact Block, 1NO/1NC, Side Mount, Mounts to Contactor | Auxiliary Contact |
Price unavailable
|
||
|
BCXML20 | Auxiliary Contact Block, 2NO, Side Mount | Auxiliary Contact |
Price unavailable
|
||
|
BLIM112-300 | MECHANICAL INTERLOCK BLK, J2 | Mechanical Interlock |
Price unavailable
|
||
|
RW117-2D3-U097 | Overload, Bim Ol Relay Class10 75-97 | RW | Bimetallic |
Price unavailable
|
|
|
RW117-2D3-U112 | Overload, Bim Ol Relay Class10 | RW | Bimetallic |
Price unavailable
|
|
|
RW317-1D3-U150 | Overload, Bim Ol Relay Class10 | RW | Bimetallic |
Price unavailable
|
|
|
RW317-1D3-U215 | Overload, Bim Ol Relay Class10 | RW | Bimetallic |
Price unavailable
|
|
|
RW317-1D3-U310 | Overload, Bim Ol Relay Class10 | RW | Bimetallic |
Price unavailable
|
|
|
RWM420E-3-A4U250 | Electronic Overload, 50A-250A | RWM |
Price unavailable
|
||
|
RWM420E-3-A4U420 | Electronic Overload, 85A-420A | RWM |
Price unavailable
|
||
|
RWM840E-3-A4U840 | Electronic Overload, 170A-840A | RWM |
Price unavailable
|
