FAZ-C32/3-NA Eaton Circuit Breakers, FAZ Series

MFG #:

FAZ-C32/3-NA

Eaton FAZ branch protector,UL 489 Industrial miniature circuit breaker - supplementary protector,Medium levels of inrush current are expected,32 A,10 kAIC, 14 kAIC,Three-pole,277/480 V,5-10X /n,50-60 Hz,Screw terminals,C Curve

View Full Specs

Skip to the end of the images gallery

Product images are for illustration purposes only. Please review specifications and documentation for exact product details.

Skip to the beginning of the images gallery

Series

FAZ

FAZ-C32/3-NA Eaton Circuit Breakers, FAZ Series

Name: FAZ-C32/3-NA Eaton Circuit Breakers, FAZ Series
Brand: Eaton
SKU: FAZ-C32/3-NA-KRMR
Price: 163.30 USD
Availability: BackOrder

MFG #:

FAZ-C32/3-NA

View Full Specs

Request Lead Time

Qty

This item cannot be canceled or returned

View Alternative Products

Specifications

Specifications
Country of Origin	Spain
Manufacturer Part Number	FAZ-C32/3-NA
Manufacturer	Eaton
Product Series	FAZ
Family Series	Eaton Circuit Breakers, FAZ Series
Poles	3
Current Rating	32 A
Max Voltage	240 VAC
Trip Curve	C
Trip Unit	Fixed Thermal / Fixed Magnetic
Mounting	DIN Rail
Neutral Pole	No
Terminal Type	Screw
Auxiliary Switch	Optional
Shunt Trip	Optional
Undervoltage Release	No
Alarm Switch	Optional
UL Standard	489
Approvals	CE, CSA, UL, VDE
H x W x D	2.36 " x 2.09 " x 3.15 "
Net Weight	0.86 lbs
Gross Weight	0.86 lbs

Alternatives

Compare available alternatives using the specifications that matter for this product.

Alternatives comparison
Image	Part	Description	Mounting	Series	Poles	Price	Action
	SU203M-C32	SU203M-C32 Miniature Circuit Breaker C-Char., 10kA, 32A, 3P UL489	DIN Rail	SU200M	3	Price unavailable
	S203U-K32	Circuit Breaker, 3-P, 32A/240VAC, K, UL489 Listed, 10KAIC, DIN Mount	DIN Rail	S200U	3	Quote Required
